Starter XTLSTR2522
Descargar PDF
Enviar consulta
No./mount. holes [ qty. ]
2 qty
O.1 [ mm ]
108 mm
No./mount. holes with thread [ qty. ]
2 qty
L.1 [ mm ]
220 mm
Rotation
CW
Size A [ mm ]
55 mm
Size B [ mm ]
34 mm
No./teeth
9 qty
No./teeth (fits into) [ qty. ]
9 qty
Power
2 kW
Oil sealed
Yes
C.1 [ mm ]
M10x1.25 mm
Voltage
12 V
C.2 [ mm ]
M10x1.25 mm
Ver más
Starter XTLSTR2522
Descargar PDF
Enviar consulta
No./mount. holes [ qty. ]
2 qty
O.1 [ mm ]
108 mm
No./mount. holes with thread [ qty. ]
2 qty
L.1 [ mm ]
220 mm
Rotation
CW
Size A [ mm ]
55 mm
Size B [ mm ]
34 mm
No./teeth
9 qty
No./teeth (fits into) [ qty. ]
9 qty
Power
2 kW
Oil sealed
Yes
C.1 [ mm ]
M10x1.25 mm
Voltage
12 V
C.2 [ mm ]
M10x1.25 mm
Inicio
Starter
Starter XTLSTR2522
Código original
17581 17748
228000-4300
2280007390
28100-50060
Código equivalente (Fabricante del vehículo)
113171 (CARGO)
F032113171 (CARGO)
17581N (WAI / TRANSPO)
17581R (WAI / TRANSPO)
17748N (WAI / TRANSPO)
20432404OE (REAL)
22.3191 (LAUBER)
25-3210 (ELSTOCK)
254385 (KUHNER)
28100-50060 (TOYOTA)
28100-50061 (TOYOTA)
28100-50062 (TOYOTA)
28100-50070 (TOYOTA)
28100-50100 (TOYOTA)
28100-50101 (TOYOTA)
28100-50110 (TOYOTA)
2810050080 (TOYOTA)
2810050081 (TOYOTA)
AEY1664 (AUTOELECTRO)
CST40404GS (CASCO)
LRS01664 (LUCAS)
LRS1664 (LUCAS)
S6063 (AS-PL)
STR5017 (WOODAUTO)
STR6260 (ELECTROLOG)
190.521.092.050 (PSH)
190.521.092.260 (PSH)
190.521.092.265 (PSH)
S130.683 (PSH)
S145.016 (PSH)
DRS0766 (DELCO)
6040404.1 (SANDO)
88213689 (POWERMAX)
PRSW157 (3EFFE)
STRW157 (3EFFE)
STX201220 (STARDAX)
Aplicaciones
Aplicaciones
ALL
TOYOTA
Marca
TOYOTA
