Starter XTLSTR3549

No./mount. holes [ qty. ]: 3 qty
O.1 [ mm ]: 90 mm
No./mount. holes with thread [ qty. ]: 0 qty
L.1 [ mm ]: 318 mm
Rotation: CW
Size A [ mm ]: 89 mm
Size B [ mm ]: 28 mm
No./teeth: 12 qty
No./teeth (fits into) [ qty. ]: 12 qty
Power: 5.5 kW

O.3 [ mm ]: 90 mm
O.2 [ mm ]: 127 mm
C.1 [ mm ]: 11.00 mm
Voltage: 24 V
C.3 [ mm ]: 11.00 mm
C.2 [ mm ]: 11.00 mm

Starter XTLSTR3549

Descargar PDF

No./mount. holes [ qty. ]: 3 qty
O.1 [ mm ]: 90 mm
No./mount. holes with thread [ qty. ]: 0 qty
L.1 [ mm ]: 318 mm
Rotation: CW
Size A [ mm ]: 89 mm
Size B [ mm ]: 28 mm
No./teeth: 12 qty
No./teeth (fits into) [ qty. ]: 12 qty
Power: 5.5 kW
O.3 [ mm ]: 90 mm
O.2 [ mm ]: 127 mm
C.1 [ mm ]: 11.00 mm
Voltage: 24 V
C.3 [ mm ]: 11.00 mm
C.2 [ mm ]: 11.00 mm

Aplicaciones

Marca	Vehículo
RENAULT	TRUCKS

Código original

30619
5001868233
M009T62671
M9T62671

Código equivalente (Fabricante del vehículo)

01182315 (KHD)
01182759 (KHD)
01183286 (KHD)
01183973 (KHD)
1182315 (KHD)
1182759 (KHD)
1183286 (KHD)
1183973 (KHD)
3050483 (KHD)
0162671 (NIERMANN)
0001241023 (BOSCH)
0001261177 (BOSCH)
0986024660 (BOSCH)
F042001228 (BOSCH)
SR5065LH (BOSCH)
114733 (CARGO)
115894 (CARGO)
F032114733 (CARGO)
F032115894 (CARGO)
20437936BN (REAL)
20437936OE (REAL)
20796052 (VOLVO)
20880693 (VOLVO)
20997669 (VOLVO)
21164603 (VOLVO)
21306350 (VOLVO)
22851149 (VOLVO)
85000749 (VOLVO)
220564 (ERA)
243-55204 (DIXIE)
S-80202 (DIXIE)
254485 (KUHNER)
254485M (KUHNER)
19801N (WAI / TRANSPO)
30619N (WAI / TRANSPO)
45-4272 (ELSTOCK)
5001868233 (RENAULT)
7420997672 (RENAULT)
7421164607 (RENAULT)
8250 (CEVAM)
88212349 (POWERMAX)
88213896 (POWERMAX)
CGB-92671 (AINDE)
CS1496 (HC PARTS)
CST35639AS (CASCO)
CST35639GS (CASCO)
19081013 (DELCO)
DRS0325 (DELCO)
SER81913-12B1 (DELCO)
M90R3568SE (PRESTOLITE)
BOS0001241023 (WOODAUTO)
MITM9T62671 (WOODAUTO)
MITM9TD1971 (WOODAUTO)
MITM9TD1981 (WOODAUTO)
STR50625 (WOODAUTO)
STR71234 (WOODAUTO)
WOOSTR50625 (WOODAUTO)
S5058 (AS-PL)
STB4123 (KRAUF)
STM3966 (KRAUF)
S24MH0075 (SIDAT)
S24MH0075A2 (SIDAT)
ANM12545X (ANDEL)
511.511.123.010 (PSH)
511.511.123.280 (PSH)
511.511.123.440 (PSH)
511.511.123.460 (PSH)
561.501.123.130 (PSH)
561.501.123.138 (PSH)
561.501.123.265 (PSH)
561.501.123.370 (PSH)
561.501.123.372 (PSH)
561.501.123.390 (PSH)
S133.948 (PSH)
S145.669 (PSH)
6035639.0 (SANDO)
6035639.1 (SANDO)
MAV376390 (SIOM)
MAV376390A (SIOM)
336468 (LOGISTIK)
PRSL660 (3EFFE)
STRF577 (3EFFE)
STRL660 (3EFFE)
LRS02599 (LUCAS)
LRS2599 (LUCAS)
STR10195 (ELECTROLOG)
STR5180 (ELECTROLOG)
STM1258 (ROLLCO)
1183209 (DEUTZ)
S100693 (BTS TURBO)
49000 (FEBI BILSTEIN)
