Starter XTLSTR0198

No./mount. holes [ qty. ]: 3 qty
O.1 [ mm ]: 103 mm
No./mount. holes with thread [ qty. ]: 0 qty
L.1 [ mm ]: 272 mm
Rotation: CW
Size A [ mm ]: 92 mm
Size B [ mm ]: 21 mm
No./teeth: 9 qty
No./teeth (fits into) [ qty. ]: 9 qty
Power: 2.2 kW

O.3 [ mm ]: 103 mm
O.2 [ mm ]: 146 mm
C.1 [ mm ]: 12.00 mm
Voltage: 12 V
C.3 [ mm ]: 12.00 mm
C.2 [ mm ]: 12.00 mm

Starter XTLSTR0198

Download PDF

No./mount. holes [ qty. ]: 3 qty
O.1 [ mm ]: 103 mm
No./mount. holes with thread [ qty. ]: 0 qty
L.1 [ mm ]: 272 mm
Rotation: CW
Size A [ mm ]: 92 mm
Size B [ mm ]: 21 mm
No./teeth: 9 qty
No./teeth (fits into) [ qty. ]: 9 qty
Power: 2.2 kW
O.3 [ mm ]: 103 mm
O.2 [ mm ]: 146 mm
C.1 [ mm ]: 12.00 mm
Voltage: 12 V
C.3 [ mm ]: 12.00 mm
C.2 [ mm ]: 12.00 mm

Applications

Make	Vehicle
LAND	ROVER

WhatsApp inquiry Email inquiry

Original Code

0001218168
2-2565-BO
33091
NAD10039

Equivalent Code (Vehicle Manufacturer)

003-H705 (ASHIKA)
101201 (KUHNER)
10543 (KUHNER)
254093B (KUHNER)
110354 (CARGO)
112439 (CARGO)
F032110354 (CARGO)
F032112439 (CARGO)
11264 (EAI)
20401411BN (REAL)
20401411OE (REAL)
22.0997 (LAUBER)
22.1201 (LAUBER)
22.1201M (LAUBER)
25-0080 (ELSTOCK)
25-3117 (ELSTOCK)
33091N (WAI / TRANSPO)
35259400 (PRESTOLITE)
35259480 (PRESTOLITE)
3677 (CEVAM)
3H705 (JAPKO)
436052 (VALEO)
525026E (VALEO)
VS104 (VALEO)
8212758 (POWERMAX)
88212758 (POWERMAX)
8816210 (FRIESEN)
8EA011610-101 (HELLA)
8EA737859-001 (HELLA)
AES7128 (AUTOELECTRO)
ALT3800 (SIOM)
MAV121140 (SIOM)
BOS0001109413 (WOODAUTO)
STR54006 (WOODAUTO)
CGB-23084 (AINDE)
CS1201 (HC PARTS)
CS543 (HC PARTS)
CST10114AS (CASCO)
CST10114GS (CASCO)
DRS3084 (DELCO)
ERR5009 (ROVER)
ERR5009E (ROVER)
LR005962 (ROVER)
NAD10039 (ROVER)
NAD100390 (ROVER)
NAD500210 (ROVER)
IS9437 (ISKRA / LETRIKA)
LRS00728 (LUCAS)
LRS728 (LUCAS)
72735640 (MAHLE)
MS12 (MAHLE)
MTH705 (JAPANPARTS)
RNL1621 (RNL)
S0042 (AS-PL)
UD12023S (AS-PL)
SS689 (SOVEREIGN)
PRSS013 (3EFFE)
STRF341 (3EFFE)
STRS013 (3EFFE)
220362 (ERA)
220883 (ERA)
S12BH0788A2 (SIDAT)
S12BH0795A2 (SIDAT)
330695 (LOGISTIK)
330742 (LOGISTIK)
331353 (LOGISTIK)
450.501.093.010 (PSH)
450.501.093.011 (PSH)
450.501.093.018 (PSH)
450.501.093.019 (PSH)
450.501.093.100 (PSH)
450.501.093.108 (PSH)
450.501.093.211 (PSH)
450.501.093.390 (PSH)
450.501.093.500 (PSH)
S132.645 (PSH)
S144.998 (PSH)
6010114.0 (SANDO)
6010114.1 (SANDO)
STR1091 (ELECTROLOG)
STM904 (ROLLCO)
0051511501 (MERCEDES)
A0051511501 (MERCEDES)
494285R (DAF)
BF5T11001AA (FORD)
NNN500210 (FORD)
ERR5009A (MAXION)
PRC4425 (LAND ROVER)
PRC5109 (LAND ROVER)
PRC5109E (LAND ROVER)
PRC5109N (LAND ROVER)
STX200303 (STARDAX)
STX200447 (STARDAX)
EZ0546 (ELTA AUTOMOTIVE)
