Starter XTLSTR1042
Download PDF
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
385 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
47 mm
No./teeth
9 qty
No./teeth (fits into) [ qty. ]
9 qty
Power
5.4 kW
O.3 [ mm ]
127 mm
Oil sealed
Yes
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
View More
Starter XTLSTR1042
Download PDF
Send Inquiry
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
385 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
47 mm
No./teeth
9 qty
No./teeth (fits into) [ qty. ]
9 qty
Power
5.4 kW
O.3 [ mm ]
127 mm
Oil sealed
Yes
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
WhatsApp inquiry
Email inquiry
Home
Starter
Starter XTLSTR1042
Original Code
0001416002
0001416078
18113
51.25201-7181
Equivalent Code (Vehicle Manufacturer)
0004156001 (MERCEDES)
0021510201 (MERCEDES)
0021515301 (MERCEDES)
002151530180 (MERCEDES)
0031514101 (MERCEDES)
0031514501 (MERCEDES)
003151450180 (MERCEDES)
0041516001 (MERCEDES)
004151600180 (MERCEDES)
0041516801 (MERCEDES)
004151680180 (MERCEDES)
0051512701 (MERCEDES)
005151270180 (MERCEDES)
7431031000 (MERCEDES)
A0021510201 (MERCEDES)
A0021515301 (MERCEDES)
A002151530180 (MERCEDES)
A0031514101 (MERCEDES)
A0031514501 (MERCEDES)
A003151450180 (MERCEDES)
A0031516101 (MERCEDES)
A0031516401 (MERCEDES)
A0041516001 (MERCEDES)
A004151600180 (MERCEDES)
A0041516801 (MERCEDES)
A004151680180 (MERCEDES)
A0051512701 (MERCEDES)
A005151270180 (MERCEDES)
A7431031000 (MERCEDES)
11.139.041 (ISKRA / LETRIKA)
11.139.506 (ISKRA / LETRIKA)
AZK5401 (ISKRA / LETRIKA)
AZK5545 (ISKRA / LETRIKA)
IS9035 (ISKRA / LETRIKA)
110206 (CARGO)
F032110206 (CARGO)
18113N (WAI / TRANSPO)
19024010 (DELCO)
19024017 (DELCO)
19024025 (DELCO)
19082013 (DELCO)
20401106BN (REAL)
20401106EL (REAL)
20401106IT (REAL)
20401106RC (REAL)
220010 (ERA)
220250 (ERA)
220276 (ERA)
220328 (ERA)
260-46211 (DIXIE)
TS-6046 (DIXIE)
33466 (EAI)
551.201.093.010 (PSH)
551.201.093.016 (PSH)
551.201.093.018 (PSH)
551.201.093.019 (PSH)
551.201.093.381 (PSH)
551.201.093.390 (PSH)
551.201.093.461 (PSH)
S133.113 (PSH)
S144.984 (PSH)
6010601.0 (SANDO)
6010601.2 (SANDO)
6010601.3 (SANDO)
6010601.5 (SANDO)
860508GB (PRESTOLITE)
8684 (CEVAM)
88212860 (POWERMAX)
8EA012586-091 (HELLA)
8EA726022-001 (HELLA)
91-15-6954 (WILSON)
943252194 (MAGNETI MARELLI)
943252210 (MAGNETI MARELLI)
MSR692 (MAGNETI MARELLI)
MSR702 (MAGNETI MARELLI)
CGB-11502 (AINDE)
CS191 (HC PARTS)
CST10601AS (CASCO)
CST10601ES (CASCO)
CST10601GS (CASCO)
CST10601OS (CASCO)
CST10601RS (CASCO)
MAV1205 (SIOM)
MAV126020 (SIOM)
MAV126380 (SIOM)
MS555 (MAHLE)
S0001 (AS-PL)
SG0470 (GHIBAUDI)
STB0191 (KRAUF)
STM905 (ROLLCO)
STR22015 (WOODAUTO)
PRSL235 (3EFFE)
STRL235 (3EFFE)
51.25201-7181 (MAN)
51.26201-7108 (MAN)
51.26201-7114 (MAN)
51.26201-7127 (MAN)
51.26201-7129 (MAN)
51.26201-7137 (MAN)
51.26201-7159 (MAN)
51.26201-7181 (MAN)
51.26201-7276 (MAN)
51.26201-9092 (MAN)
51.26201-9117 (MAN)
51.26201-9125 (MAN)
51.26201-9127 (MAN)
51.26201-9159 (MAN)
51.26201-9181 (MAN)
51262017092 (MAN)
51262017109 (MAN)
51262017125 (MAN)
51262017273 (MAN)
S24BH0058A2 (SIDAT)
12590 (EFEL)
1516707R (DAF)
1516711R (DAF)
STR1047 (ELECTROLOG)
STR7928 (ELECTROLOG)
STR79477 (ELECTROLOG)
060532943 (CASE)
1326930 (CLAAS)
5000822346 (RENAULT)
5001000061 (RENAULT)
6001075 (LIEBHERR)
7431024000 (KASSBOHRER)
7431026000 (KASSBOHRER)
PTC-4004 (POWER TRUCK)
Applications
Applications
ALL
MAN
Make
MAN
