Starter XTLSTR1069
Download PDF
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
406 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
No./teeth (fits into) [ qty. ]
11 qty
Power
6.6 kW
O.3 [ mm ]
127 mm
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
View More
Starter XTLSTR1069
Download PDF
Send Inquiry
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
406 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
No./teeth (fits into) [ qty. ]
11 qty
Power
6.6 kW
O.3 [ mm ]
127 mm
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
WhatsApp inquiry
Email inquiry
Home
Starter
Starter XTLSTR1069
Original Code
0001410098
0001417007
277451
Equivalent Code (Vehicle Manufacturer)
10121 (KUHNER)
254320 (KUHNER)
254566 (KUHNER)
110212 (CARGO)
F032110212 (CARGO)
20401046BN (REAL)
20401046EL (REAL)
20401306BN (REAL)
20401306EL (REAL)
20401336BN (REAL)
20401336EL (REAL)
22.0121 (LAUBER)
28.0121 (LAUBER)
170743 (SCANIA)
277451 (SCANIA)
309220 (SCANIA)
309470 (SCANIA)
349578 (SCANIA)
349581 (SCANIA)
349587 (SCANIA)
571423 (SCANIA)
571460 (SCANIA)
571461 (SCANIA)
33546 (EAI)
33601 (EAI)
33602 (EAI)
438047 (VALEO)
455535 (VALEO)
45-0150 (ELSTOCK)
45-0313 (ELSTOCK)
45-0381 (ELSTOCK)
4782801 (IVECO)
6010603 (SANDO)
6010633 (SANDO)
6010640 (SANDO)
SRO46001 (SANDO)
SSR60001 (SANDO)
81467045 (MONARK)
860510GB (PRESTOLITE)
860514 (PRESTOLITE)
860514GB (PRESTOLITE)
860515GB (PRESTOLITE)
860517 (PRESTOLITE)
860517GB (PRESTOLITE)
8690 (CEVAM)
8812480 (FRIESEN)
8EA725974-001 (HELLA)
911.202.113 (PSH)
911.202.113.210 (PSH)
S136.162 (PSH)
S145.200 (PSH)
AES7146 (AUTOELECTRO)
CGB-11645 (AINDE)
CRO46001AS (CASCO)
CSR60001AS (CASCO)
CST10603AS (CASCO)
CST10603ES (CASCO)
CST10603RS (CASCO)
CST10633AS (CASCO)
CST10633ES (CASCO)
CST10640AS (CASCO)
CST10640ES (CASCO)
CS121 (HC PARTS)
DRS2480 (DELCO)
IM361 (AVF)
IM645 (AVF)
LRS00746 (LUCAS)
LRS746 (LUCAS)
MAV1214 (SIOM)
MAV126180 (SIOM)
MAV126400 (SIOM)
MAV2260 (SIOM)
STR22056 (WOODAUTO)
STRS058 (3EFFE)
STRS686 (3EFFE)
S0220 (AS-PL)
220234 (ERA)
220235 (ERA)
220324 (ERA)
S24BH0042A2 (SIDAT)
12800 (EFEL)
STR10139 (ELECTROLOG)
STR1655 (ELECTROLOG)
1516692R (DAF)
6244321 (VOLVO)
Applications
Applications
ALL
SCANIA
Make
SCANIA
