Starter XTLSTR4017 | SINTLY
Previous slide
Next slide
Starter XTLSTR4017
Download PDF
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
112 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
213 mm
Rotation
CW
Size B [ mm ]
13.5 mm
No./teeth
10 qty
No./teeth (fits into) [ qty. ]
10 qty
Power
1.3 kW
O.3 [ mm ]
117 mm
O.2 [ mm ]
33 mm
C.1 [ mm ]
12.50 mm
Voltage
12 V
C.3 [ mm ]
12.50 mm
C.2 [ mm ]
12.50 mm
View More
Starter XTLSTR4017
Download PDF
Send Inquiry
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
112 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
213 mm
Rotation
CW
Size B [ mm ]
13.5 mm
No./teeth
10 qty
No./teeth (fits into) [ qty. ]
10 qty
Power
1.3 kW
O.3 [ mm ]
117 mm
O.2 [ mm ]
33 mm
C.1 [ mm ]
12.50 mm
Voltage
12 V
C.3 [ mm ]
12.50 mm
C.2 [ mm ]
12.50 mm
WhatsApp inquiry
Email inquiry
Home
Starter
Starter XTLSTR4017
Original Code
32554
5802N4
D6RA107
D6RAP404
Equivalent Code (Vehicle Manufacturer)
0986023480 (BOSCH)
101290 (KUHNER)
11930 (EAI)
20479452OE (REAL)
20479691OE (REAL)
20479691RC (REAL)
22.1290 (LAUBER)
22.1290M (LAUBER)
25-3048 (ELSTOCK)
32554R (WAI / TRANSPO)
3857 (CEVAM)
5802CV (PEUGEOT)
5802CZ (PEUGEOT)
5802N4 (PEUGEOT)
5802V9 (PEUGEOT)
5802W6 (PEUGEOT)
5802X7 (PEUGEOT)
5802X8 (PEUGEOT)
9657391280 (PEUGEOT)
6015196 (SANDO)
6015254 (SANDO)
71723464 (RENAULT)
7711134302 (RENAULT)
7711134529 (RENAULT)
820053977 (RENAULT)
9627267180 (RENAULT)
9635501280 (RENAULT)
8080178 (FRIESEN)
88213084 (POWERMAX)
8EA738135001 (HELLA)
AEU1290 (AUTOELECTRO)
CS1290 (HC PARTS)
CST15196GS (CASCO)
CST15196RS (CASCO)
CST15254GS (CASCO)
CST15254OS (CASCO)
DRS3737 (DELCO)
LRS01554 (LUCAS)
LRS1554 (LUCAS)
MAV2040 (SIOM)
RNLD6RA70 (RNL)
S3085 (AS-PL)
SS318 (SOVEREIGN)
STRS707 (3EFFE)
220527 (ERA)
STR0025 (ELECTROLOG)
S12VA0239 (SIDAT)
S12VA0239A2 (SIDAT)
ANM15957X (ANDEL)
331260 (LOGISTIK)
STA0438R (BOVEZ)
K9635501280 (FIAT)
STX200164 (STARDAX)
STX200325 (STARDAX)
STX200325R (STARDAX)
STX200410 (STARDAX)
STX200410R (STARDAX)
42023480 (HERTH+BUSS)
Applications
Applications
ALL
PEUGEOT
Make
PEUGEOT
