Starter XTLSTR4102
Download PDF
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
74 mm
No./mount. holes with thread [ qty. ]
3 qty
L.1 [ mm ]
221 mm
Rotation
CW
Size A [ mm ]
74 mm
Size B [ mm ]
20 mm
No./teeth
10 qty
Power
1.5 kW
O.3 [ mm ]
74 mm
O.2 [ mm ]
105 mm
C.1 [ mm ]
M6x1.0 mm
Voltage
12 V
C.3 [ mm ]
M10x1.5 mm
C.2 [ mm ]
M10x1.5 mm
View More
Starter XTLSTR4102
Download PDF
Send Inquiry
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
74 mm
No./mount. holes with thread [ qty. ]
3 qty
L.1 [ mm ]
221 mm
Rotation
CW
Size A [ mm ]
74 mm
Size B [ mm ]
20 mm
No./teeth
10 qty
Power
1.5 kW
O.3 [ mm ]
74 mm
O.2 [ mm ]
105 mm
C.1 [ mm ]
M6x1.0 mm
Voltage
12 V
C.3 [ mm ]
M10x1.5 mm
C.2 [ mm ]
M10x1.5 mm
WhatsApp inquiry
Email inquiry
Home
Starter
Starter XTLSTR4102
Original Code
12417835126
19015
458236
D7G13
Equivalent Code (Vehicle Manufacturer)
11090295 (EUROTEC)
12162 (EAI)
12417835126 (BMW)
12417835737 (BMW)
7835126 (BMW)
7835737 (BMW)
19015R (WAI / TRANSPO)
20479332OE (REAL)
210.534.102 (PSH)
S131.998 (PSH)
220795 (ERA)
25-4268 (ELSTOCK)
254490 (KUHNER)
254490V (KUHNER)
3925 (CEVAM)
6015233.1 (SANDO)
91-20-3556 (WILSON)
AEY2595 (AUTOELECTRO)
CGB-54268 (AINDE)
CST15233GS (CASCO)
DRS0243 (DELCO)
DS1353 (DELCO)
LRS02595 (LUCAS)
LRS2595 (LUCAS)
S-6562 (DIXIE)
STV3236 (KRAUF)
UD17050S (AS-PL)
VAL438188 (WOODAUTO)
STR00262 (ELECTROLOG)
S12VA0607A2 (SIDAT)
5015882 (MEAT & DORIA)
STX201393 (STARDAX)
Applications
Applications
ALL
BMW
Make
BMW
