Starter XTLSTR4507
Download PDF
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
136 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
289 mm
Rotation
CW
Size A [ mm ]
105 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
Power
4.5 kW
O.3 [ mm ]
112 mm
O.2 [ mm ]
112 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
View More
Starter XTLSTR4507
Download PDF
Send Inquiry
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
136 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
289 mm
Rotation
CW
Size A [ mm ]
105 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
Power
4.5 kW
O.3 [ mm ]
112 mm
O.2 [ mm ]
112 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
Applications
Original Code
30051600003
65.26201-7077
Equivalent Code (Vehicle Manufacturer)
231.002.113 (PSH)
S131.574 (PSH)
S148.705 (PSH)
8214256 (POWERMAX)
8241 (CEVAM)
S-80294 (DIXIE)
S9277 (AS-PL)
UD12909S (AS-PL)
STD0013 (KRAUF)
STR85204 (WOODAUTO)
WhatsApp inquiry
Email inquiry
Starter XTLSTR4507
STRL762 (3EFFE)
