Starter XTLSTR1048
下载 PDF
发送询盘
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
386 mm
Rotation
CW
Size A [ mm ]
89 mm
Size B [ mm ]
47 mm
No./teeth
11 qty
Power
5.5 kW
O.3 [ mm ]
89 mm
Oil sealed
Yes
O.2 [ mm ]
89 mm
C.1 [ mm ]
11.00 mm
Voltage
24 V
C.3 [ mm ]
11.00 mm
C.2 [ mm ]
11.00 mm
查看更多
Starter XTLSTR1048
下载 PDF
发送询盘
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
386 mm
Rotation
CW
Size A [ mm ]
89 mm
Size B [ mm ]
47 mm
No./teeth
11 qty
Power
5.5 kW
O.3 [ mm ]
89 mm
Oil sealed
Yes
O.2 [ mm ]
89 mm
C.1 [ mm ]
11.00 mm
Voltage
24 V
C.3 [ mm ]
11.00 mm
C.2 [ mm ]
11.00 mm
适用车型
原厂编码
0001416036
2-3174-2W
30773
42498250
替代编码 (汽车制造商)
01171955 (KHD)
01174639 (KHD)
01174645 (KHD)
1171955 (KHD)
3040680 (KHD)
10384 (KUHNER)
11.139.013 (ISKRA / LETRIKA)
AZK5173 (ISKRA / LETRIKA)
IS9013 (ISKRA / LETRIKA)
110535 (CARGO)
F032110535 (CARGO)
16372N (WAI / TRANSPO)
20401826BN (REAL)
20401826EL (REAL)
22.0384 (LAUBER)
28.0384 (LAUBER)
33631 (EAI)
45-1370 (ELSTOCK)
455616 (VALEO)
621.000.0 (ELMOT)
R23-21 (ELMOT)
81466036 (MONARK)
860655GB (PRESTOLITE)
860656GB (PRESTOLITE)
8694 (CEVAM)
8812730 (FRIESEN)
8EA726132-001 (HELLA)
CGB-11536 (AINDE)
CS384 (HC PARTS)
CST10628AS (CASCO)
CST10628ES (CASCO)
DRS2730 (DELCO)
IM536 (AVF)
LRS00748 (LUCAS)
LRS748 (LUCAS)
MAV126260 (SIOM)
MAV126280 (SIOM)
72736194 (MAHLE)
MS566 (MAHLE)
STR22018 (WOODAUTO)
PRSS903 (3EFFE)
STRS903 (3EFFE)
220322 (ERA)
330536 (LOGISTIK)
22620 (EFEL)
6010628.0 (SANDO)
6010628.3 (SANDO)
STR1648 (ELECTROLOG)
STR79443 (ELECTROLOG)
42498250 (IVECO)
42522680 (IVECO)
42526680 (IVECO)
8121335 (IVECO)
1516756R (DAF)
1701063 (FAUN)
C9JF11350A (FORD)
D6PZ11350C (FORD)
