Starter XTLSTR1081
下载 PDF
发送询盘
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
430 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
Power
6.7 kW
O.3 [ mm ]
127 mm
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
查看更多
Starter XTLSTR1081
下载 PDF
发送询盘
No./mount. holes [ qty. ]
3 qty
O.1 [ mm ]
127 mm
No./mount. holes with thread [ qty. ]
0 qty
L.1 [ mm ]
430 mm
Rotation
CW
Size A [ mm ]
92 mm
Size B [ mm ]
48 mm
No./teeth
11 qty
Power
6.7 kW
O.3 [ mm ]
127 mm
O.2 [ mm ]
127 mm
C.1 [ mm ]
13.50 mm
Voltage
24 V
C.3 [ mm ]
13.50 mm
C.2 [ mm ]
13.50 mm
首页
Starter
Starter XTLSTR1081
原厂编码
0001330042
0001371006
10571168
19780
替代编码 (汽车制造商)
101061 (KUHNER)
101061B (KUHNER)
101061P (KUHNER)
111910 (CARGO)
F032111910 (CARGO)
10571168 (SCANIA)
1352290 (SCANIA)
1357709 (SCANIA)
1357709S6111 (SCANIA)
1358639 (SCANIA)
1516656 (SCANIA)
561571462 (SCANIA)
571168 (SCANIA)
571427 (SCANIA)
571463 (SCANIA)
19780N (WAI / TRANSPO)
20401506BN (REAL)
20401506EL (REAL)
28.1061 (LAUBER)
28.1061M (LAUBER)
45-2178 (ELSTOCK)
458174 (VALEO)
81391006 (MONARK)
81392006 (MONARK)
8501 (CEVAM)
860305 (PRESTOLITE)
860514 (PRESTOLITE)
860514GB (PRESTOLITE)
860549 (PRESTOLITE)
8817760 (FRIESEN)
88213036 (POWERMAX)
8EA012586-031 (HELLA)
8EA737403-001 (HELLA)
CGB-27760 (AINDE)
CGB-27760R (AINDE)
CGB-52178 (AINDE)
CS1061 (HC PARTS)
CST10605AS (CASCO)
CST10605ES (CASCO)
19070035 (DELCO)
19070037 (DELCO)
19084004 (DELCO)
DRS7760 (DELCO)
11.139.176 (ISKRA / LETRIKA)
AZJ3488 (ISKRA / LETRIKA)
IS9148 (ISKRA / LETRIKA)
LRS01897 (LUCAS)
LRS1897 (LUCAS)
MAV126050 (SIOM)
72483654 (MAHLE)
MS524 (MAHLE)
RNL1776 (RNL)
S0024 (AS-PL)
STR22086 (WOODAUTO)
PRSL827 (3EFFE)
STRL827 (3EFFE)
ANM19980X (ANDEL)
331213 (LOGISTIK)
911.002.113.010 (PSH)
911.002.113.215 (PSH)
911.002.113.310 (PSH)
911.002.113.380 (PSH)
S135.733 (PSH)
943210611010 (MAGNETI MARELLI)
MSRC1061 (MAGNETI MARELLI)
6010605.0 (SANDO)
6010605.3 (SANDO)
8013501 (ZM)
ZM8013501 (ZM)
STR1208 (ELECTROLOG)
1516656R (DAF)
PTC-4006 (POWER TRUCK)
适用车型
适用车型
ALL
SCANIA
品牌
SCANIA
